| S536 |
|
| DTMB Tuner |
|
|
|
| Product Features: |
|
| 1-way tuner input: Support DVB-C,DVB-T,DVB-S,DVB-S2,ABS-S |
| 2-way independent TS input(Optional) |
| Support PSI/SI Processing,PCR Correction |
| Support Arbitrary PID filtering and mapping |
| In line with the GB20600-2066 standards for 330 kinds of models all |
| Support network management |
| Technical Parameters |
| 2-way TS input: |
CVBS Composite Video,BNC/75Ω interface,S-VIDEO interface |
| 1-way RF input: |
F-Type interface,Support DVB-C,DVB-T,DVB-S,DVB-S2,ABS-S |
| 1-way TS output: |
DVB standard ASi format,BNC/75Ω interface |
| 1-way IF monitor output: |
BNC/75Ω interface |
| 1-way RF output: |
output Frequency: 45-860MHZ frequency agile |
| Stepped-frequency: 100KHZ |
| Output Level: 85-113dBuv |
| Stepped-level: 0.5dB |
| The number of modulated carrier 1,3780 |
| Modulation:4QAM-NR,4QAM,16QAM,32QAM,64QAM |
| Guard interval:1/4(945),1/7(595),1/9(420) |
| Network Management Interface: |
RJ45 Interface(10/100M Adaptive) |
| General: |
| Operating Temperature: |
5-45℃ |
| Storage Temperature: |
-25-80℃ |
| Humidity: |
10-75% |
| Power supply: |
AC 90-260V 50/60Hz 20W |
| Dimensions: |
483mmx350mmx44mm |
| Weight: |
3kg |
