| S606 |
|
| MPEG-2 Standard Definition Encoder |
|
|
| Product Features: |
|
| MPEG-S Standard(ISO/IEC 13818) |
| MPEG-S Standard(ISO/IEC 13818) |
| Audio Compression Standard ISO/IEC11172-3(Layerl and Layerll) |
| Packaging,Reuse Standards ISO/IEC 13818-1 |
| Support GOP,Optional Encoding(IPB,IP,IBI,I) |
| Support MPEG-2 Frame/Field motion estimation and DCT |
| Support Full Resolution D1,3/4D1,2/3D1,Half D1,SIF,QSIF |
| Output Rate per:1.5-16Mbps Adjustable |
| MPEG-2 Adaptive Field Frame(AFF) |
| Technical Parameters |
| Video input: |
CVBS Composite Video,BNC/75Ω interface,S-VIDEO interface |
| Audio input: |
L/R Non-equilibrium Audio,BNC/75Ω interface |
| Stream Output: |
1-way Stream output,ASI Format,BNC/75Ω interface |
| Video Encoding; |
BNC/75Ω interface |
| Encoding Format: |
MPEG-2 MP&ML Standard |
| Support Full Image Resolution: |
Support Full Image Resolution: |
| D1: |
PAL(720X576),NTSC(720X480) |
| 3/4 D1: |
544X576 |
| 2/3 D1: |
480X576 |
| Half-D1: |
352X576 |
| SIF: |
352X288 |
| QSIF: |
176X144 |
| Bit Rate control mode: |
10bit A/D Quantitative |
| Audio Encoding: |
Audio Encoding: |
| Encoding Format: |
MPEG Layerl and Layerll Standard |
| Sampling Frequency: |
32KHz,44.1KHz,48KHz |
| Coding Rate: |
64KHz-512KHz Adjustable |
| General: |
| Operating Temperature: |
5-45℃ |
| Storage Temperature: |
-25-80℃ |
| Humidity: |
10-75% |
| Power supply: |
AC 90-260V 50/60Hz 20W |
| Dimensions: |
483mmx350mmx44mm |
| Weight: |
3kg |
