| S616 |
|
| Professional Decoder |
|
|
|
| Product Features: |
|
|
|
| 2-way TS input or 2-way Tuner input |
|
| 12-way Decoder output |
|
| MpEG-2 MP&ML Standard |
|
| MPEG Layer I/II Audio Standard |
|
| Support real-time programs to choose from |
| Descrambling function(Optional) |
|
| Multiplexing stream output(Optional) |
|
| Technical Parameters |
|
| Signal input: |
2-way ASI Stream input,BNC/75Ω interface or 1-way RF input F-Type interface |
| Support DVB-C,DVB-T,DVB-S,DVB-S2,ABS-S |
| TS output: |
1-way ASI Stream output BNC/75Ω interface (Optional multiplexing TS or Descrambling TS) |
| 12-way Video and Audio output: |
CVBS Composite Video,RCA interface |
| L/R Stereo,RCA interface |
| General: |
| Operating Temperature: |
5-45℃ |
| Storage Temperature: |
-25-80℃ |
| Humidity: |
10-75% |
| Power supply: |
AC 90-260V 50/60Hz 20W |
| Dimensions: |
483mmx350mmx44mm |
| Weight: |
3kg |
