234477/234478
2 way outerdoor optical receiver
Frequency Range	47-750 MHZ   or
	53-750 MHZ   or
	87-750 MHZ   or
	87-860 MHZ
Wave  length	1310/1550 nm
Equivalent Yawp Current	7
Input Light Power	-6-+2 dBm
Light Power Detect	10V/Wm
Light Tie-in Type	FC/APC(SC/UPC)
Light Return Loss	≥40dB
RF Return Loss	≥16dB
Response Flatness	+ 0.75dB  (47-750MHZ)
Gain Range	0-18dB
Slope Range	0-18dB
Representative Light Power	-1  dBm
Ghannel Number(PAL-D)	59
Output Level	86-100 dBuV
CNR	52dB
CSO	60dB
CTB	65dB
Signal to AC Noise	66 dB
Resist Lightning Strike	5KV (10/700uS)
Operation Voltage	30-75220V±10%
Power Loss	0.8A/24V
