indoor optical node (receiver ), with return transmission
| Item Number: |
|
| 234486 |
|
| Packaging Details: |
|
| 1pc/box 10 pcs/carton 36x26x28cm/ 0.0262cbm 11/10 kgs |
|
|
| |
  |
| |
| Product Description |
- 234486
- indoor optical node (receiver ), with return transmission
| Features |
| 1) Especially designed for FTTH, FTTP, FTTO, FTTS |
| 2) Adopting Pin diode as Photo electricity modules |
| 3) Adopting Gallium Arsenide Modules as amplifying modules |
| 4) AGC control |
| 5) 1310&1550 double windows, two outputs |
| 6) With return transmission |
| Technical Parameters: |
| Forward Input: |
-10~+3 (-3~+1 is the best value) |
| Wave length: |
1100nm~1600nm |
| Frequency: |
54-862MHz |
| Output: |
¡Ý82dBV |
| Unflatless: |
¡Ü¡À1 |
| Optical Return Loss |
¡Ý 45dB |
| Output Return Loss |
¡Ý 16dB |
| Output Impendence: |
75¦¸ |
| Output Level: |
¡Ý100dBuV |
| CTB |
¡Ý65dB |
| CNR |
¡Ý51dB |
| CSO |
¡Ý60dB |
| Power Supply: |
DV12V~15V |
| Return Transmission: |
| Laser: |
FP/DFB |
| Output: |
0.5mW, 1mW, 2mW |
| Wave length: |
1310nm¡À30nm or 1550¡À30nm |
| Optical Connector: |
SC/APC or FC/APC |
| Bandwidth: |
5-42MHz |
| Output Impedance: |
75¦¸ |
| Output Return Loss: |
¡Ý 14dB |
| Input Level: |
85-90dBuV |
| Unflatless: |
¡Ü¡À1 | |
|
| |
|
|
